                  • Flexible Belt
                    • Features
                    • Constant tension, easy installation, and wear- resistance.Tensile cords centered enable wear resistance and antistatic value under 1MΩ
                    • Facebook
                    • Plurk
                    • Twitter
                  • Inquiry

          • Introduction
          • Belt Specification
          • Pulley Specifications
          • Ordering example
            •

              Structure

              Specification X Type B Type C Type
              Profile
              Material PU elastomer

              Because of the casting method and the capillary effect, allowing the superior bonding with tensile cords.

              Integrally formed profiles, providing belts with accuracy and stability.
              Cord None Ultra tensile cords
              Structure Composed of PU material without cords. Tensile cords lined in the bottom of belts with PU on the top Tensile cords centered and surrounded with PU completely
              Merit and demerit

              †High wear resistant PU can be applied on instruments with high belt speeds and inextensible demand.

              †Without tensile cords, this type belts cause elastic fatigue after a long run.

              †Short manufacturing process and low cost.

              † Tensile cords lied in the bottom of belts can be damaged after long operation.

              †Tensile cords centered enable wear resistance and antistatic value under 106Ω.

              †Complicated manufacturing process, thickness required over 0.65mm and high cost

              Property

              Breaking strength 13.65 N/mm width
              Breaking elongation 200%
              Min. diameter 8mm
              Temperature limit -20+80℃
              Friction Mat side 0.35~0.6
              Smooth side 0.4~0.8
              Unit mass 0.82 Kg/m2

              Feature

              ● Free of maintenance
                Compared with chains or gears, the cost of lubrication and maintenance is few.
              ● Low pre-tension
                Only low initial tensioning, motor and bearing loads are minimized, enjoying longer belt life.
              ● Constant tension
                No pre-tensioning required
              ● Smooth transmission
                Flexible belt is integrally formed polyurethane (PU). Based on excellent bonding and structure, tension is constant.
              ● Dimensional stability
                Excellent structure and bonding , constant belt thickness and width enable smooth running.
              ● Cleanness
                High wear resistant PU minimizes dusting and is especially suitable for clean rooms, food and beverage industry.
              ● Oil resistance
                Conditionally resistant to oils, grease and fuel.
              ● Temperature range
                Under room temperature, it is from -20°C to 95°C.
              ● Climate resistance
                Suitable for tropical climates.
                Resistant to aging, ozone, hydrolysis and UV
              ● Counterbending
                Special and high quality component. Belts are suitable for bending applications
              ● Environmental friendly
                Certificated by REACH Commission. Low dusting, provided non-marking structure. Free of carbon black.
              ● Antistatic
                Antistatic belt is made-to-order. The whole one is electronically conductive and conforms to ≤ 106 Ω. Resistance remains steady and will not lower following a long-run operaion.
              ● Acid and alkali resistance
                Conditionally resistant to acid and lye.
              ● Wear-resistant
                Ten times higher than rubber belts.
              ● Anti-solvent
                Conditionally anti-solvent.
              ● Hardness
                Standard hardness is 83 Shore A
              ● Various specifications
                A wide range of specs are available. Customized width enables the costs down.
              ● Applications
                Banking and currency-handling (e.g., ATM, change machine, ticket vending machine, automated ticket checker, card conveyor, friction feed unit, bill identifier, fare box and card reader.)
                Office equipment and business machines (e.g., photo booth, photo sticker booth, laser printer, gaming machine and semiconductor conveyor.)
                Printing and paper industry (e.g., un-winder and folder gluer machine.)
                Packaging equipment (e.g., labeling.)
                Power transmission (e.g., power machine, micro power transmission, high-speed balancing and internal grinding machine.)
            • Should you wish to place an order, please contact us!

              Model Length Thickness   Model Length Thickness   Model Length Thickness
              FX-64.5 64.5 1.47   FX-261 261.0 0.65   FX-463 463.0 1.00
              FX-89 89.0 0.80   FX-263 263.0 0.80   FX-468 468.0 0.65
              FX-120 120.0 0.65   FX-267 267.0 0.65   FX-470 470.0 0.65
              FX-128 128.0 0.65   FX-272 272.0 0.65   FX-485.5 485.5 0.65
              FX-130 130.0 0.65   FX-273 273.0 1.00   FX-485.5 485.5 1.00
              FX-135 135.0 0.65   FX-277.5 277.5 1.00   FX-502 502.0 0.65
              FX-138 138.0 0.70   FX-278 278.0 0.65   FX-513 513.0 0.65
              FX-143 143.0 0.65   FX-290 290.0 0.65   FX-533 533.0 1.00
              FX-145 145.0 1.30   FX-291 291.0 1.00   FX-544 544.0 0.80
              FX-150.5 150.5 0.58   FX-292 292.0 0.80   FX-548 548.0 0.94
              FX-153 153.0 0.65   FX-293 293.0 0.65   FX-551 551.0 0.80
              FX-156 156.0 0.65   FX-301 301.0 0.65   FX-572 572.0 0.65
              FX-156 156.0 1.20   FX-303.5 303.5 1.00   FX-600 600.0 1.00
              FX-160 160.0 0.65   FX-320 320.0 1.85   FX-607 607.0 0.65
              FX-160 160.0 1.1   FX-322 322.0 0.65   FX-619 619.0 0.65
              FX-168 168.0 0.65   FX-332 332.0 1.00   FX-653 653.0 0.65
              FX-175 175.0 1.50   FX-341 341.0 0.65   FX-685 685.0 1.00
              FX-177 177.0 0.65   FX-344 344.0 0.80   FX-720 720.0 0.9
              FX-181 181.0 1.20   FX-348 348.0 0.65   FX-724 724.0

              0.65

              FX-181 181.0 1.50   FX-352 352.0 0.65   FX-726 726.0 0.90
              FX-184 184.0 0.65   FX-360 360.0 0.65   FX-800 800.0 1.20
              FX-190 190.0 0.65   FX-361 361.0 0.80   FX-820 820.0 0.65
              FX-190 190.0 1.20   FX-368 368.0 0.65   FX-862 862.0 0.65
              FX-193 193.0 0.65   FX-370 370.0 0.94   FX-870 870.0 0.65
              FX-207 207.0 1.10   FX-371 371.0 0.65   FX-890 890.0 0.65
              FX-207 207.0 1.30   FX-382 382.0 0.65   FX-986 986.0 0.65
              FX-208 208.0 0.65   FX-397 397.0 0.65   FX-1001 1001.0 0.65
              FX-214 214.0 0.65   FX-402 402.0 0.65   FX-1010 1010.0 1.20
              FX-218 218.0 1.10   FX406 406.0 0.65   FX-1066 1066.0 0.65
              FX-222 222.0 0.65   FX-427 427.0 1.20   FX-1116 1116.0 1.00
              FX-230 230.0 0.90   FX-429 429.0 0.65   FX-1143 1143.0 0.65
              FX-231 231.0 0.65   FX-437 437.0 0.65   FX-1207 1207.0 1.00
              FX-235 235.0 0.65   FX-452 452.0 0.65   FX-1260 1260.0 5.40
              FX-237 237.0 1.00   FX-452.5 452.5 1.20   FX-1332 1332.0 1.00
              FX-237 237.0 1.20   FX-457 457.0 1.10   FX-1332 1332.0 1.60
              FX-244 244.0 0.65           FX-1476 1476.0 1.00
              FX-248 248.0 0.65
              FX-250 250.0 0.65





              •

            • FX-320-0.65X10-C
